  • Strong, secure, and energy efficient designs
  • Passive House Certified, Net Zero, and Step-Code 5 energy options
  • Double, triple, quadruple, and LiteZone® glazing options
  • Concealed hinge’s available
  • Tilt before turn, tilt-only, and balcony door hardware options
  • Magnetic assist closing options
  • Insect screens available from the factory

Tilt & Turn Windows

Tilt and turn windows both tilt and turn, controlled by the turning of a single handle. Windows open to the inside meaning glass can easily be cleaned in hard to reach places. Modern style aluminum cladding is available.

​North America’s only Change of Profile window!

  • Our advanced machines change the shape of a window frame along a single piece of wood to switch from an operable window to a fixed piece of glass. Mulling windows together (when multiple separate windows are screwed together to form one larger one) is a thing of the past!
  • Profile changing achieves an increased glass area, window strength is improved, manufacturing costs are reduced, and there is decreased installation efforts.
  • Industry leading 150kg (330lb) weight capacity hinges allows for larger windows to be built using heavier & thicker glass providing:
  • more natural light
  • improved energy efficiency
  • better thermal insulation
  • reduced noise transmission
  • Optional micro-ventilation tilting

Fixed and direct glaze

Picture windows do not open, rather they hold glass in places or areas where opening is not possible or required. Without hinges or other hardware components to restrict the size or weight required for smooth operation, fixed windows can be constructed to span large widths and heights above and beyond any operable window, and should be used where large unobstructed views are desired without the need for access to the outdoors. All our picture windows are fully customizable, and match our opening windows and doors.

Push Out Windows

Our push out windows are one-of-a-kind.. Over 1000 design & engineering hours were invested into our window line, with input from multiple countries including Canada, the USA, Germany, Austria, Italy, England, and the Czech Republic. Extremely unique and rare, these
windows are both flush with the interior and exterior side of the frame, feature two air and water-tight continuous gaskets around the perimeter (one on either side of the hardware to protect it from the environment), and are constructed to exceed expectations and demands of a humid coastal environment. Locks can wrap-around the window corners to
provide multiple locking points on 1, 3, or all 4 sides for high security and sealing performance.

Systems


POPULAR CONFIGURATIONS

Any style, design, or shape is possible thanks to wood's maximum design flexilbity!


  • Single Operable Window
  • Picture Window
  • Combination Window
  • 1 Operable Window, 1 Fixed Window
  • Custom Combination Window
  • Custom Shapes
  • Custom Shapes
  • Custom Combination Window
  • -No Mulling!
  • Custom Combination Window
  • -No Mulling!
  • Custom Combination Window
  • -No Mulling!
  • Custom Combination Window
  • -No Mulling!
  • Double or French Windows
  • Custom Combination Window
  • -No Mulling!
  • Custom Combination Window
  • -No Mulling!
  • Hopper Window
Prev
Next

KEY PERFORMANCE DATA


WINDOWS & DOORS

LOW-E OPTIONS
CENTER-OF-GLASS DATA
(U-VALUE OF WINDOW) PER NFRC METHOD [W/(m2-K)]
90% Argon Fill, Warm Edge Spacer
U
SHGC
FIXED
Casement
TILT & TURN
Lift and slide
Euro swing door

STANDARD DOUBLE GLAZED

Sb60
1.40
0.40
S1.16
1.48
0.61

PREMIUM DOUBLE GLAZED (2 LowE Coatings)

Sb60/Sb60
1.36
0.37
S1.16/S1.16
1.41
0.57

Standard Triple Pane

Sb60
1.05
0.36
S1.16
1.20
0.52
DblCoat
1.10
0.34

Premium Triple Pane (2+ LowE Coatings)

Sb60 (#2,#5)
0.70
0.34
S1.16 (#2, #5)
0.75
0.48
DblCoat (#2, #5)
0.75
0.32
S10 (#2, #5)
0.73
0.42
D70 (#2, #5)
0.73
0.29

SUGGESTED MIN/MAX SIZES – INCHES

DIFFERENT SIZES AVAILABLE BY SPECIAL DESIGN CONSIDERATION & ENGINEERING.

TYPE
MIN WIDTH
MIN HEIGHT
MAX WIDTH
MAX HEIGHT
PG
MAX WEIGHT (Operable section)
NOTE

Windows

Fixed Glass
14″
14″
60″
98″
CW70
n/a
Fixed Glass
14″
14″
123″
118″
CW55
n/a
Fixed Glass
14″
14″
228″
228″
n/a
Requires engineering, 228″ max size in one direction.
Tilt and Turn Window
18″
18″
60″
102″
CW70
330lb/150kg
Hopper Window
18″
18″
96″
96″
CW70
330lb/150kg
Casement Window
18″
24″
34″
60″
CW60
100lb/45kg
Awning Window
18″
18″
96″
48″
CW45
260lb/120kg

Doors

Euro Swing Door
30″
80″
44″
96″
CW45
660lbs/300kg
Swing doors should maintain a minimum 2:1 height:width ratio
Euro Swing Door
30″
80″
44″
96″
CW75 Limited Water
660lbs/300kg
Inswing Door – Double Drilled
24″
n/a
36″
80″
R40
660lbs/300kg
Outswing Door – Double Drilled
24″
n/a
36″
80″
R40
660lbs/300kg
Inswing Door – Multipoint Lock
24″
n/a
60″
104″
CW40
660lbs/300kg
Outswing Door – Multipoint Lock
24″
n/a
42″
96″
R45
660lbs/300kg
Outswing French Door
24″
n/a
42″
96″
R35
660lbs/300kg

Lift and Slides

Lift Slide – OX
72″
80″
168″
156″
LC30
880lb/400kg
Lift Slide – OXXO
144″
80″
312″
156″
LC30
880lb/400kg

Resources


Window

Fenstur Product Catalogue

Fenstur Catalogue
youtube
Window

Window Installation – Strap Method

Video
Window

Tilt and Turn Sample Installation – Center of Wall

PDF
Window

Tilt and Turn Sample Installation – Flush with Exterior Wall

PDF


Wood Finishes

NOTE: Colors represented on screen may differ from physical product colors.
When selecting a standard frame color, please request a color sample kit.

Hardware

  • Screens
  • Exterior Window Sills
  • Exterior Window Sills
  • Handle Upgrades
  • Handles
  • Tilt before Turn Hardware
  • Multipoint Locks
  • Multipoint Locks

Glass

Our windows can be glazed with any type of glass you desire. Double, triple, or even quadruple pane energy efficient glass is available or custom textures, patterns, safety, and obscure glass.
